Load 400-1600kg Safe Commercial Elevator For Shopping Mall / Office / Hotel

Name: Load 4001600kg Safe Commercial Elevator For Shopping Mall Office Hotel
Brand: SUNNY
Price: 7000 USD

Wholesale Load 400-1600kg Safe Commercial Elevator For Shopping Mall / Office / Hotel from china suppliers

Brand Name : SUNNY

Model Number : Commercial Elevator

Certification : CE,ISO9001

Place of Origin : China

MOQ : 1Set

Price : $7000-12000

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 Set/ Year

Delivery Time : 15~30 days

Packaging Details : container

Name : Commercial Elevator

Load : 450-1600kg

People : 4-21

Speed : 1-4

Application : Apartment, Shopping Malls, Office, Hotel, Villa, a

Traction Ratio : 2:1

Elevator type : Passenger Elevators

Type : Elevators

Control : VVVF Elevator Control System

Keywords : Passenger Elevator Lift

Product : Commercial Elevator

Product name : Commercial Elevator

Contact Now

Safe Commercial Elevator For Shopping Mall / Office / Hotel , Load 400-1600kg

Commercial elevator

·Stable, low running noise, comfortable, eco-efficiency, automatic error recording

·Adopts the three advanced technologies: synchronous permanent-magnetic (SPM) gearless traction machine, microcomputer serial communication system and variable voltage variable frequency control (VVVF)

·Traction machine is just half size of the traditional one, but better driving efficiency with lower motor power. The running noise and vibration is greatly reduced because of abandon of worm gear.

·Minimum machine room design and machine roomless design save most of the building space, improve the usage percentage.

Technical parameter for machine room type elevator:

Load(kg)	Person	Speed(m/s)	Car size(mm)	Door open(mm)	Shaft size(mm)
320	4	1.0	9509402440	700*2100	1600*1650
450	6	1.0/1.5/1.6/1.75	115010502440	800*2100	1900*1750
630	8	1.0/1.5/1.6/1.75	140011002440	800*2100	2000*1800
800	10	1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0	140013502440	800*2100	2000*2050
1000	13	1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0	160014002440	900*2100	2200*2100
1150	15	1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0	170015002440	1000*2100	2300*2200
1250	16	1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0	170016002440	1000*2100	2300*2300
1350	18	1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0	180016002440	1000*2100	2400*2300
1600	21	1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0	200017002440	1100*2100	2700*2600

Our hot products:

Load 400-1600kg Safe Commercial Elevator For Shopping Mall / Office / Hotel

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
